Uses Overview:
Apply to industrial and mining enterprises, scientific research institutes, medical units, drying, baking laboratory wax melting, heat treatment .
Features:
1.The shell is made of good quality cold rolled steel manufacturing, electrostatic spraying the surface treatment technology, modeling elegant, corrosion-resistant and durable.
2.The chamber is made of stainless steel or high quality steel plate processing and embalmed, adjustable height , four angle is half arc, easy to clean.
3.Double liner design, two or three sides of the heating is safe and reliable, beautiful appearance, convenient opening, small occupied space, factories manufacturing, office experimental ideal.
4.Omnibearing stereo heating and forced air circulation technology, to ensure uniform temperature in the studio.
5.Double layer glass observation window, the studio samples shelf height adjustable, observation of clear, easy to use.
6.Intelligent digital display temperature control instrument precision, ensures the temperature without overshoot, with timing, temperature alarm function.
7.One-button start or stop, with a power indicator light, working lights, current output instructions, ensure the safe operation of equipment.
8.Equipped with an independent over-temperature protection device, once over temperature fault the system will cut off all power, guarantee the safety of equipment.
9.Good insulation design, long-term operation at high temperature, long service life, convenient replacement, green, energy-saving, environmental protection.
10.Use high-temperature silicone seal, with the locking type adjustable door lock, ensure good sealing performance, prevent heat loss.
11.Unique geometric cavity clean design, to ensure the sample active perfect protection.
12.Inheritance of aesthetic design, show the elegant luxury of instrument modeling.
The main technical parameters:
| Model |
DHG-45A DHG-45B |
DHG-75A DHG-75B |
DGF-1A DGF-1B |
DGF-2A DGF-2B |
DGF-3A DGF-3B |
DGF-4A DGF-4B |
DGF-4A-II DGF-4B-II |
| Voltage |
220V |
380V |
| Tem. range(℃) |
Room temperature+10-250℃ |
| Tem.motion(℃) |
±1℃ |
| Input power |
1KW |
1.5KW |
2.2 KW |
3.4KW |
4.8KW |
6KW |
6.6KW |
Interior dimensions W×D×H(mm) |
320× 350× 400 |
370× 400× 500 |
450× 450× 600 |
500× 550× 700 |
600× 650× 800 |
700× 700× 1000 |
800× 800× 1000 |
Exterior dimensions W×D×H(mm) |
480× 490× 700 |
530× 530× 800 |
600× 650× 1060 |
660× 750× 1160 |
760× 850× 1260 |
860× 900× 1460 |
960× 1000× 1460 |
| Shelf load |
25KG | (Note: 1、A is galvanized steel liner, B is stainless steel liner.DGF-4-II is a double door design. 2、DHG series of temperature control system in the bottom of the instrument. ) |
