Uses Overview:
Hot air sterilizer / drying sterilization box using physical methods for sterilization, use dry heat on microbial oxidation, protein denaturation, poisoning by dielectric concentration effect, which is mainly through oxidation damage cell protoplasm, the microbial death, so in a certain heating time can kill all kinds of microorganism.
Features:
1.Using intelligent PID liquid crystal temperature control instrument, with the timing, alarm, over-temperature protection function, PT100 temperature sensor temperature measuring accuracy and reliability.
2.Omnibearing stereo heating and forced air circulation technology, to ensure uniform temperature in the studio.
3.With over temperature power-down, alarm indication system,when controlling the temperature exceeds the set upper limit instrumentautomatically cut off the power output buzzer alarm.Ensure that the experiment, and the safety of the personnel
4.Perfect insulation design, long-term operation at high temperature, long service life, convenient replacement, green, energy saving and environmental protection.
5.Use high-temperature silicone seal, with the locking type adjustable door lock, ensure good sealing performance, prevent heat loss.
6.Box door is provided with a double-layer tempered glass, easy to observe the objects inside the heating case in the studio.
7.Case made of high quality cold rolling steel with spaying surface, modeling nice, anti-corrosion and durability.
8.Unique geometric cavity clean design, to ensure the sample active perfect protection.
9.Working room is made of stainless steel ,Adjustable electrochemical polishing of stainless steel plate, four horns in a semicircular arc,.Easy to be cleaned .The height of shelf could be adjusted.
10.Inheritance of aesthetic design, show the elegant luxury of instrument modeling.
11.With fan switch, can choose to open or close the fan.
The main technical parameters:
| Model |
GRX25B |
GRX40B |
GRX70B |
GRX120B |
| Voltage |
AC220V 50HZ |
| Tem. range(℃) |
室温+5-250℃ |
| Tem. motion(℃) |
±1℃ |
| Input power |
600W |
1000W |
1500W |
2000W |
| Interior dimensions W×D×H(mm) |
270×280×350 |
350×360×350 |
400×400×450 |
450×500×550 |
| Exterior dimensions W×D×H(mm) |
400×410×700 |
480×490×700 |
530×530×800 |
580×630×900 |
| Shelf load |
15KG | ( Note:the product performance parameter test in: no-load test, ambient temperature ≤ 20 ℃,environment humidity 50%RH measured under the conditions.) |
